Cylindrical Ring Gages - Steel / Chrome

  • Ring Gage inspects the external dimensions of manufactured parts
  • A Ring Gage can also be used to set an instrument, air or electronic
  • An annular groove in the periphery of the NO GO ring distinguishes it from the GO ring
  • Gagemakers tolerance will be applied minus on the GO and plus on the NO GO
  • Gages are ring lapped to size and hand polished to provide superior accuracy and wearability
  • Non-gage areas are black oxided and ring faces are surface ground
  • Roundness and taper will not exceed 50% of the applicable gagemakers size tolerance and are non-accumulative
  • Ring gages above 5.510” are not supplied with tapped holes for ball handles unless specified
  • Manufactured in accordance with ANSI/ASME B89.1.6
  • Gage blanks meet all the requirements of B47.1
  • Ring gage blanks go through a stabilization process, cycling through temperature extremes from -130°F to +300°F
  • Gages inspected for size and class in a temperature-controlled lapping room
  • Final inspection of gages is completed in a separate, environmentally controlled ISO 17025 laboratory
  • Available in steel, chrome and carbide
  • Free NIST certificate of accuracy
