Hex Gage - Metric - Steel - ZZ - 5 - GO/NOGO/HANDLE - ANSI B18.3

Hex Gage - Metric - Steel - ZZ - 5 - GO/NOGO/HANDLE - ANSI B18.3

Hex Gage - Metric - Steel - ZZ - 5 - GO/NOGO/HANDLE - ANSI B18.3

Regular price $323.00 $293.00 Sale

Hex Gage
Part#HXM09B18
classZZ
memberGO-/-NOGO
specANSI-B18.3
size 5
MeasureMetric
materialSteel
Email Express Quote

*Please choose GO or NOGO Member

WESTport Corporation offers a complete range of GO/NOGO Hex plug gages manufactured to ANSI/ASME specifications with in fractional sizes from .028" to 3.00" and metric sizes from .70mm to 75.00mm. The standard covers dimensional data for various types of hexagon and spline socket cap screws, shoulder screws, set screws, and hexagon and spline keys recognized as the American Standard. Gages are manufactured from oil hardened tool steel with a minimum HRC of 60 HRC. Hex gages are perfect for inspecting machine head fasteners. WESTport Corporation can also build custom hex plug gages per customer specifications.


  • ANSI/ASME B107.17M
  • ANSI B18.3
  • Price includes Go, Nogo and Handle
  • Steel material and Class ZZ tolerances
  • NIST traceable
  • Tool Steel: 60/62 Rc (Cold Stabilized)
  • Long Form Calibration available at an additional charge

partHXM09B18
classZZ
memberGO-/-NOGO
specANSI-B18.3
size 5
MeasureMetric
materialSteel
