Fowler Standard Micrometers - 16 - 20 Inch - Inch - .001 Inch - Interchangeable Anvil

Fowler Standard Micrometers - 16 - 20 Inch - Inch - .001 Inch - Interchangeable Anvil

Fowler Standard Micrometers - 16 - 20 Inch - Inch - .001 Inch - Interchangeable Anvil

Regular price $773.00 $696.00 Sale

Interchangeable Anvil Inch Micrometer
Part#52-401-205-1
size 16---20-Inch
MeasureInch
gradiation .001-Inch
typeMicrometer Interchangea
Email Express Quote

Fowler's Interchangeable Anvil Micrometers are very popular in machine and auto repair and for all other applications requiring a versatile micrometer. Each micrometer is equipped with a series of easily interchangeable anvils to fulfill the ranges listed. Standards are also included to accurately adjust the required range.

Features:

  • Hammertone blue baked enamel frame.
  • Graduations (.001" or .01mm) are microfine on satin chrome for easy reading.
  • Each anvil is fitted with an adjusting collar to set the overall dimension.
  • Spindle thread is hardened and precision ground with microlap finish on carbide tipped measuring faces.
  • Diameter of measuring face: .256" (0-”12") or .295" (12-”20")
  • Ratchet stop ensures exact readings.
  • A wrench is included for fast, easy zero adjustment on the sleeve.
  • Positive lever locking clamp assures accurate settings.
  • Standards are included with each set.
  • Accuracy: .001" for 0-”1" (.01mm for 0-”25mm)
  • Parallelism: .0004" for 0-”1" (.010mm for 0-”25mm)
  • Flatness: .00003" (.00076mm)
  • Includes fitted case.

part52-401-205-1
size 16---20-Inch
MeasureInch
gradiation .001-Inch
typeMicrometer Interchangea
